JTX TOOLS JTX IR-3 Motherboard Short Circuit Finder Pad is a professional thermochromic silicone detection tool designed to quickly locate short circuits and overheating components on phone motherboards, PCBs, and electronic devices. Compared to thermal imaging camera detection, this innovative IR-3 detection pad uses temperature-sensitive color-changing technology, turning white when the temperature is ≥35°C, thus instantly and accurately locating hot spots. Cost-effective, smoke-free, and reusable alternative for repair technicians and phone repair shops.
Features:
1. 35°C Thermochromic: Color change begins at approximately 35°C, quickly identifying abnormal heat points.
2. Quick White Dot Location: The white color-changing area serves as a visual indication of heat points/suspected short circuits.
3. 0.5mm Flexible Sheet: Soft and bendable, making it easier to adhere to the motherboard and different component surfaces.
4. High Transparency Design: Allows observation of the motherboard circuitry and components beneath the temperature sensor, aiding in accurate fault location determination.
5. Reusable: Utilizes reversible thermochromic material; color changes are triggered at ≥35°C, and the color returns to its original state below 35°C, allowing for repeated use.
6. No Complex Adjustment Required: Unlike thermal imaging equipment, it does not require focusing or calibration, making operation simpler.
7. Smokeless and Odorless: Eliminates the need for high-temperature heating testing with rosin, keeping the repair workbench cleaner.
8. Low-Cost Testing Solution: Suitable for routine, high-frequency motherboard short-circuit troubleshooting by repair personnel.
9. Quick Three-Step Testing: Attach to motherboard → Power-on test → Locate heat source based on white color-changing dots.
10. Applicable to Various Motherboards: Can be used to locate short-circuit heat sources on different types of electronic motherboards.
11. Application: Phone motherboard repair; PCB diagnostics; BGA rework preparation; Quality control; Field repair.
Product Specifications
Brand: JTXTOOLS
Model: IR-3
Product Name: Short-Circuit Finder Pad
Detection Temperature: ≥35°C
Material: Reversible Thermochromic Silicone
Thickness: 0.5mm
Feature: Flexible, Transparent, Reusable
Color Change: ≥35°C: Color changes; <35°C: Returns to original color
Function: Detects PCB/motherboard short-circuit heat sources
Package Size: 13x65x143mm
Gross Weight: 21.5g
