How to Fix iPhone XS Battery Draining Quickly
iPhone XS power draining too fast after upgrading iOS? In the iPhone standby state, the battery power of the iPhone XS will still be exhausted quickly. This problem has several potential causes. After troubleshooting the software problem, we think it is a problem with the iPhone XS hardware. We need open iPhone XS to fix this issue.

First of all, we need to disassemble the iPhone XS. Use 3D screwdrivers to remove the screws at the bottom of the iPhone screen, and then use other phone opening tools to open the iPhone XS screen.

We try to fix this problem by replacing the iPhone XS battery. Remove the iPhone screen, disconnect the iPhone battery, and then take out the iPhone battery.

Install a new iPhone XS battery, assemble the iPhone XS, and test it, but the problem is still the same, the iPhone XS battery still drains quickly. So it's not the problem of the iPhone XS battery, next we need to check iPhone XS motherboard.

Disassemble the iPhone XS again, remove the iPhone screen, disconnect the iPhone battery, and then take out the iPhone motherboard.

Measure the iPhone XS motherboard by DC power supply to check current, we found it leaks 300mA, and we found that this iPhone XS was repaired before, because there are traces of layering.

Put iPhone XS motherboard on the MJ CH5 separating station to separate the layer. After separating, we can see that the layers doesn't match well.

Clean the tin on the middle layer, and then measure it, but the problem is still the same.

Observe the iPhone motherboard under a Double Trinocular Microscope, we found the problem, a capacitor blackened. Login to the ZXW online account, we know this is a filter capacitor of the iPhone main power supply PP_VDD_MAIN.

Use soldering iron to remove it directly, and then use DC power supply to measure the iPhone XS motherboard, now the current tested is normal.

Assemble the iPhone XS motherboard layer, and then assemble the iPhone XS. Turn on the iPhone XS, all functions tested are normal, and then iPhone battery drains properly.

Have you ever had a problem with iPhone XS battery power draining too fast? Do you have any other troubleshooting tips? Share them with us in the comments.
