How Do You Pick Infrared Thermal Imager for Phone PCB Repair

The common faults of our mobile phones are generally short circuit, open circuit or poor contact. When encountering these faults, what tool we can use for easily and efficiently detecting them? Here, China PHONEFIX Team will introduce some cost-effective thermal imaging cameras to solve your mobile phone repair failure.

How Do You Pick Infrared Thermal Imager for Phone PCB Repair

Experienced repairers should know that the use of thermal imaging has a certain effect on the repair of mobile phone motherboards, and the efficiency is also very high. Thermal imaging is mainly suitable for the following cellphone motherboard faults:

1. IC short circuit causes temperature rise, the circuit board current is large when the short circuit occurs, and the corresponding part has a temperature rise, so its infrared thermal image is significantly higher than normal;

2. Capacitor leakage causes temperature rise;

3. The circuit board temperature rises due to short circuit after soaking in water;

4. Poor contact of the connector leads to temperature rise.

It can be seen from the above failure phenomenon that most of the problems that can be detected are temperature rise phenomenon, because the principle of thermal imaging detection is that there is a level of temperature difference imaging. High cost performance can consider the following thermal imaging cameras:

How Do You Pick Infrared Thermal Imager for Phone PCB Repair

1. MobIR Air Thermal Imaging Camera

The MobIR Air Thermal Imaging Camera is an anti-peep temperature detection thermal imager for Smartphone type-c Android and IOS devices. It can detect and fix the HVAC issues quickly and accurately, and the thermal imager can be also used for patrol at night.

2. P30 Plus Pocket IR Thermal Imager

The P30 Plus Pocket IR Thermal Imager is a very convenient hand-held tool for beginners without any professional training. It is quick to start and it also supports various measurement methods.

How Do You Pick Infrared Thermal Imager for Phone PCB Repair

3. QIANLI Super Cam 3D Thermal Imager

You will use QIANLI one-button power cord to supply power to the cellphone motherboard, and adjust the display mode to thermal imaging mode. The 3D thermal imager will enable the software quickly detect faulty parts. It can be connected to the computer USB interface through the adapter, which is more convenient to use and avoids the network cable interface being occupied.

To get more choices of infrared thermal Imager and professional phone repair guide on www.vipfixphone.com
